Specifications
Adhesion Stainless Steel Grate Style
Fixed Length: Pre-pitched channel with set length with center outlet location
Waterproofing: PVC/Vinyl liner, Lead/copper pan, Hot mop, Rubber liner, Fiberglass
16 gauge, 304 stainless steel perforated top grate with stainless steel channel
Overall width: 2-13/16″, Min. height above waterproofing: 1-5/16″
Capacity: 9 gallons per minute
Requires 2″ clamp down floor drain with 2″ throat (strainer size). Not included in complete kit.
FXGR 6524: 24″ Complete Kit
FXGR 6532: 32″ Complete Kit
FXGR 6536: 36″ Complete Kit
FXGR 6542: 42″ Complete Kit
FXGR 6548: 48″ Complete Kit
FXGR 6560: 60″ Complete Kit
Satin Stainless — SS
Polished Stainless — PS
Satin Bronze — SB
Oil Rubbed Bronze – ORB
Matte Black — BK
Matte White — MW
Gunmetal — GM
Satin Champagne — SC
Polished Gold — PG
Polished Brass — PB
Satin Brass — SR
Resources
Hair Maintenance
All of our drains include a complimentary Hair Maintenance kit
This kit includes:
- Hair Basket
- Lift-out key
- User Guide
- Storage Pouch
