ND 4

Specifications

Features

ND 4

Center Drain: Requires traditional 4-way floor pitch

7 Gauge- 3/16″ thick stainless steel decorative top plate

4″ x 4″ Internally Pitched Stainless Steel Strainer and Throat

Capacity: 9 gallons per minute per outlet.

Includes 2″ clamp down floor drain with 2″ throat (strainer size)

Compatible with UCR 2

Components Required:

N 4 Strainer Kit (Finish code must be specified when ordering (e.g., SS for Satin Stainless)

UCR 2

Avaliable Models

ND 4-2

ND 4-2I: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key, and Cast Iron clamp down drain with 2″ outlet

ND 4-2P: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key, and PVC clamp down drain with 2″ outlet

ND 4-2A: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key, and ABS clamp down drain with 2″ outlet

NDB 4

NDB 4-P: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key, and PVC Bonded Flange

NDB 4-A: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key, and ABS Bonded Flange

NDB 4-S: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key, and Stainless Steel Bonded Flange

Strainer Only

N 4 (finish code required)

Includes: 4″ decorative top plate, 2″ throat, hair strainer, lift-out key

Standard Finishes Available

Satin Stainless — SS

Polished Stainless — PS

Satin Bronze — SB

Oil Rubbed Bronze – ORB

Matte Black — BK

Matte White — MW

Gunmetal — GM

Satin Champagne — SC

Polished Gold — PG

Polished Brass — PB

Satin Brass — SR
