Specifications
Fixed Length: Pre-pitched channel with set length with center outlet location
Waterproofing: PVC/Vinyl liner, Lead/copper pan, Hot mop, Rubber liner, Fiberglass
12 gauge, 316 stainless steel wedge wire top grate with stainless steel channel
Overall width: 4-5/16″, Min. height above waterproofing: 1-11/16″
Capacity: 21 gallons per minute
3″ clamp down floor drain with 4″ throat (strainer size) included in complete kit
FXAS 10032: (1) 32″ Complete Kit
FXAS 10036: (1) 36″ Complete Kit
FXAS 10042: (1) 42″ Complete Kit
FXAS 10048: (1) 48″ Complete Kit
FXAS 10060: (1) 60″ Complete Kit
Satin Stainless — SS
Polished Stainless — PS
Satin Bronze — SB
Oil Rubbed Bronze – ORB
Matte Black — BK
Matte White — MW
Gunmetal — GM
Satin Champagne — SC
Polished Gold — PG
Polished Brass — PB
Satin Brass — SR
Resources
Hair Maintenance
All of our drains include a complimentary Hair Maintenance kit
This kit includes:
- Hair Basket
- Lift-out key
- User Guide
- Storage Pouch
