Specifications
16 gauge, 304 stainless steel perforated top grate with Stainless Steel channel
Fixed Flange with Schluter®-KERDI: Pre-pitched channel with set length with center outlet location.
Waterproofing: Liquid membrane, Fabric sheet
Overall width: 1-1/2″ Min. height above subfloor*: 13/16″
Capacity: 9 gallons per minute
No-hub connection to waste line with rubber coupling (not included)
Specialty channel installation options available FCB 65, FCH 65
FCSLT 3832: (1) 32″ Complete Kit
FCSLT 3836: (1) 36″ Complete Kit
FCSLT 3842: (1) 42″ Complete Kit
FCSLT 3848: (1) 48″ Complete Kit
FCSLT 3860: (1) 60″ Complete Kit
Satin Stainless — SS
Polished Stainless — PS
Satin Bronze — SB
Oil Rubbed Bronze – ORB
Matte Black — BK
Matte White — MW
Gunmetal — GM
Satin Champagne — SC
Polished Gold — PG
Polished Brass — PB
Satin Brass — SR
Hair Maintenance
All of our drains include a complimentary Hair Maintenance kit
This kit includes:
- Hair Basket
- Lift-out key
- User Guide
- Storage Pouch
