Specifications
Fixed Flange: Pre-pitched channel with set length with center outlet location
Factory applied Schluter° Kerdi Membrane
12 gauge, 304L stainless steel tile insert frame with stainless steel channel
Finished width: 2-1/2″, Min. height above subfloor*: 1-1/2″
Capacity: 9 gallons per minute
No-hub connection to waste line with rubber coupling (not included)
Only the inner frame finish is visible; the outer frame is concealed
FCSDTIF 6524: (1) 24″ complete kit
FCSTIF 6536: (1) 36″ complete kit
FCSTIF 6548: (1) 48″ complete kit
Satin Stainless — SS
Polished Stainless — PS
Satin Bronze — SB
Oil Rubbed Bronze – ORB
Matte Black — BK
Matte White — MW
Gunmetal — GM
Satin Champagne — SC
Polished Gold — PG
Polished Brass — PB
Satin Brass — SR
Resources
Hair Maintenance
All of our drains include a complimentary Hair Maintenance kit
This kit includes:
- Hair Basket
- Lift-out key
- User Guide
- Storage Pouch
