RMD 5

Specifications

Features

RMD 5

Center Drain: Requires traditional 4-way floor pitch

7 Gauge- 3/16″ thick stainless steel decorative top plate

5″ Round Internally Pitched Stainless Steel Strainer and Throat

Compatible with UCR 2
Components Required:

RM 5 Strainer Kit (Finish code must be specified when ordering (e.g., SS for Satin Stainless)

UCR 2

Avaliable Models

RMD 5-2

RMD 5-2I: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key, and Cast Iron clamp down drain with 2″ outlet

RMD 5-2P: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key, and PVC clamp down drain with 2″ outlet

RMD 5-2A: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key, and ABS clamp down drain with 2″ outlet

RMD 5-3

RMD 5-3I: 5″ decorative top plate, 4″ throat, hair strainer, lift-out key, and Cast Iron clamp down drain with 3″ outlet

RMD 5-3P: 5″ decorative top plate, 4″ throat, hair strainer, lift-out key, and PVC clamp down drain with 3″ outlet

RMD 5-3A: 5″ decorative top plate, 4″ throat, hair strainer, lift-out key, and ABS clamp down drain with 3″ outlet

RMDB 5

RMDB 5-P: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key, and PVC Bonded Flange

RMDB 5-A: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key, and ABS Bonded Flange

RMDB 5-S: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key, and Stainless Steel Bonded Flange

Strainer Only
RM 5 (finish code required)

Includes: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key

Standard Finishes Available

Satin Stainless — SS

Polished Stainless — PS

Satin Bronze — SB

Oil Rubbed Bronze – ORB

Matte Black — BK

Matte White — MW

Gunmetal — GM

Satin Champagne — SC

Polished Gold — PG

Polished Brass — PB

Satin Brass — SR
