LTD 5

Specifications

Features

Center Drain: Requires traditional 4-way floor pitch

5″ x 5″ ABS & Stainless Steel Body

Stainless Tile Insert for 3/8″ material

Capacity: 8 gallons per minute per outlet.

Avaliable Models

LTD 5-2

LTD 5-2I: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key, and Cast Iron clamp down drain with 2″ outlet

LTD 5-2P: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key, and PVC clamp down drain with 2″ outlet

LTD 5-2A: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key, and ABS clamp down drain with 2″ outlet

LTD5 B

LTD5 BP: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key, and PVC Bonded Flange

LTD5 BA: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key, and ABS Bonded Flange

LTD5 BS: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key, and Stainless Steel Bonded Flange

Strainer Only
LT 5 (finish code required)

Includes: 5″ Stainless Tile Insert for 3/8″ material, 2″ throat, hair strainer, lift-out key

Standard Finishes Available

Satin Stainless — SS

Polished Stainless — PS

Satin Bronze — SB

Oil Rubbed Bronze – ORB

Matte Black — BK

Matte White — MW

Gunmetal — GM

Satin Champagne — SC

Polished Gold — PG

Polished Brass — PB

Satin Brass — SR
