FFAS 65

Fixed Flange: Pre-pitched channel with set length with center outlet location

Waterproofing: Liquid membrane, Fabric sheet

12 gauge, 316 stainless steel wedge wire top grate with stainless steel channel

Finished width: 2-1/2″, Min. height above subfloor*: 13/16″

Capacity: 9 gallons per minute

No-hub connection to waste line with rubber coupling (not included)

Recess channel into subfloor with placement brackets ST 65

Specialty channel installation options available FCB 65, FCH 65

FFAS 6524: (1) 24″ Complete Kit

FFAS 6532: (1) 32″ Complete Kit

FFAS 6536: (1) 36″ Complete Kit

FFAS 6542: (1) 42″ Complete Kit

FFAS 6548: (1) 48″ Complete Kit

FFAS 6560: (1) 60″ Complete Kit

Satin Stainless — SS

Polished Stainless — PS

Satin Bronze — SB

Oil Rubbed Bronze – ORB

Matte Black — BK

Matte White — MW

Gunmetal — GM

Satin Champagne — SC

Polished Gold — PG

Polished Brass — PB

Satin Brass — SR

• FFAS 65 Submittal

• Fixed Flange Series – Installation Instructions

• FFAS 65 DXF CAD File

FT Installation
Liquid / Fabric Waterproofing
